Free Shipping 36V lithium ion battery protection circuit 10S 36V/37V 15A BMS ON/OFF switch wires and small size L65*W40mm

Free Shipping 36V lithium ion battery protection circuit 10S 36V/37V 15A BMS ON/OFF switch wires and small size L65*W40mm

Precio habitual $28.99 Precio de oferta $50.99 Precio unitario por
Impuesto incluido. Los gastos de envío se calculan en la pantalla de pagos.

Free Shipping! 36V lithium ion battery protection circuit, 10S 36V/37V 15A BMS, ON/OFF switch wires and small size.

10M15A-SW-02

Feature

1. It is suitable for 10S 36V lithium ion battery pack.

2. With functions of protection from voltage, current detection, including over-current, overvoltage, under-voltage and short circuit protection.

3. This BMS has applied with high quality IC chip specially for lithium battery protection purpose .highly detection
precision degree on over-charge,over-discharge ,and with detection on wires disconnection functions,
with three layers of over-discharge and over-current detections and delay times in detecting process.( Over-current 1,
over current 2,short cicircuit protection ),with charging protection functions at the charging port so as to avoid reverse

connection problem from the charger . short-circuit of charging port ,with two layers protection against over-voltage
when charging :This is The PCB for 10 series 36V(42v)  lithium ion  battery pack with  15A constant  discharge current

and Max 3A charging current  .the charge and discharge port is different.

10M15A-SW-0410M15A-SW-0510M15A-SW-07

Wiring instructions:

power wiring harness

B-:Connect to battery negative  (3135 Black  14AWG  L=150±5mm)

P-:Connect to negative of discharge port (3135 Blue  14AWG  L=150±5mm)

C-:Connect to negative of charge port (3135 yellow  18AWG  L=150±5mm)



Voltage monitoring wiring harness

Line type:UL1007   22AWG   L=300±5mm
B-(Black),B10+(Red)
B-(GND)/B1/B2/B3/B4/B5/B6/B7/B8/B9/B10(B+)

Remarks:

Please connect B- line firstly, and then connect voltage monitoring wiring harness. The last step is to connect charge and discharge lines. If you want to remove them, the order should be reversed. Please pay attention to the connection order, or it will damage the component.



Electrical Characteristic (Ta=25 ºC)

No.

Test Item

Min.

Typ.

Max

Unit

1

Input Charging Voltage



42V



V

2

Input Charging Current



2

3

A

3

Output Discharging Current



15



A

4

Over-Current Discharging Protection

45

50

55

A

5

Current Consumption



25

32

uA

6

Over-Charge Protection Voltage

4.17

4.2

4.25

V

7

Over-Charge Protection Voltage Delay Time

1.0

1.5

2.0

S

8

Over-Discharge Protection Voltage

2.67

2.75

2.83

V

9

Over-Discharge Protection Voltage Delay Time

1.0

1.5

2.0

mS

10

Short Circuit Protection Release

Remove the load

11

Impedance



7

12

12

Operating Temperature

-20

+25

+50

ºC

13

Storage Temperature

-20

+25

+45

ºC



SMT


Origin: CN(Origin)
Weight: 0.08KG
Size: L65*W40*T10.5mm
Model Number: 10M15A02
Nominal Capacity: 5-30Ah
Application: 10S 36V li-ion
Type: Li-ion battery BMS
Voltage: 36V
Product name: 10S 36V 15A li-ion BMS
Rated Voltage: 36V/37V
Charging voltage: 42V
Continuous working current: 15A
Dimensions: L65*W40*T10.5mm
Composed Type: 10S
Charging Current: 2A
