24S 84v Lithium Smart BMS PCB Balance 24S 86V 88.8v 100.8v Li-ion Lipo UART Android Bluetooth App

Product Description :

24S 84v 40A 60A 100A 80A 50A Lithium Smart BMS PCB Balance 24S 86V 88.8v 100.8v Li-ion Lipo with UART Android Bluetooth App

This is the BMS of 24S with * continuous discharge current .


Features:

 Perfect over-charger, over-discharge, over-current and short circuit protection functions.
 Suitable for 24S 84V  lifepo4  battery.

Size:  20*110*280mm,

Adjustable Parameters:

Parameter can set by software(APP).
Balance current: 50mA
Charge voltage: 4.20V * 24= 100.8V
3.2v lifepo4 cells is 3.65v * S= charging voltage.
3.7v li-ion lipo cells is 4.25v/4.20 * S= charging voltage.
Size:  20*110*280mm,

Adjustable Parameters:
1.Balance voltage setup: Balance voltage Range:  3.3-4.2V
2.Over-voltage voltage setup: Charge voltage Range :   3.6-4.3V
3.Under-voltage voltage setup: Discharge voltage Range :  2.0-3.3V
4.Over Charge/Discharge current Setup....

Product parameters:

Brand Name: BATTERXPERT
Accessory Type: Battery Accessories
Model Number: C639
